How to Create a Retro Magazine Illustration in Illustrator and Photoshop

February 10, 2019 1 Comment

How to Create a Retro Magazine Illustration in Illustrator and Photoshop

In this tutorial, I'll be showing you how to create a charming retro mid-century Better Homes & Gardens inspired magazine illustration using Adobe Illustrator and Adobe Photoshop..

We will be using TransferTone | Dry Transfer Patterns for Adobe Illustrator, along with some other RetroSupply goodies. These swatches are perfect for adding those awesome retro patterns to your artwork. I'm super excited to test them out!

TransferTone | Dry Transfer Patterns for Adobe Illustrator

TransferTone is our tribute to the mesmerizing world of transfer rub-on products. Includes 85 unique patterns inspired by dry transfers of the 70s and 80s.

Step 1. Gather Inspiration and Reference

I searched pinterest for mid-century kitchens and appliances and Better Homes and Gardens lifestyle illustrations from the 60s. I’ve always loved the images in old lifestyle magazines, casual sexism aside — this era of advertising really reflected the (elusive) promise of the American dream.

Create a mood board highlighting key elements you wish to emulate. I also used these images as inspiration for a possible palette. Think 2 to 5 colors max. I see lots of pink, turquoise, and buttercup yellows combined with wood and stone. I love the simplicity of the top illustrations as well as the detailed, shiny renderings of the others; I will be going for something in between those two styles, hopefully creating something nostalgic but unique.

Mid-century kitchen inspiration for illustration

Step 2. Open Adobe Illustrator and Set Up Your File

Create a file suitable for print, 8.25 x 10.75 with 1/4” bleed. Open the TransferTone swatches and import any vector brushes you wish to use. I will also be using the VectorHero Brushes (also available from The Vector Brush Toolbox), and The Dead Pen Toolkit to create some nifty line work to add that mid-century look and feel.

We will be building a 1/2 page illustration, creating adequate space for some theoretical ad copy.

Mid-century illustration color palette

Step 3. Create a Rough Comp

You can start sketching in illustrator or import a drawing, whatever you prefer! I like to use a vanishing point for reference because I like it precise, but wonky shapes and flat objects would be just as swell.

Create vanishing point lines for your illustration.

You are basically creating the bones of your illustration. I’ll use my lines to create my perspective guides by going to View > Guides > Make Guides. It doesn’t have to be perfect, but it’s nice to have because we will be creating some tiled floors that we will need transform. It’s going to look pretty technical and boring at this stage so be patient.

Create guides in Adobe Illustrator

Step 4. Add Details

Start building your shapes with the Pen tool and play around with the TransferTone swatches.

You can edit the colors of the swatches by double-clicking the swatch in the swatch panel. Select the main element and choose your desired color from the color picker. I’ve opted for 4 colors for now -- they can always be changed later on.

Working with swatches in Adobe Illustrator

Now it's time to add the pattern to your artwork. To use the TransferTone swatches, I will apply the pattern to a shape. If I am using a color behind the swatch, I will copy the shape and paste it in place over top (Command + F) and select the desired pattern from the swatch panel.

These are the TransferTone swatches I used for the final vectors:

  • Dust (counter)
  • Vertical Lines (window)
  • Strokes (curtains)
  • Vertical Wood (cupboards)
  • Wonky Grid (kitchen tiles)
  • Drops (towels)
  • Mosaic (stonework)
  • MCM Wallpaper (floor tiles)
  • MCM Brick
Dry Transfer textures from TransferTone for Adobe Illustrator

Now that we have applied our patterns, we can start refining our shapes.

I often like to soften my shapes by rounding the corners of objects. You’ll find that option in Effects > Stylize > Rounded Corners. Play around with the size options to get the corners you want.

Rounding corners in Adobe Illustrator

I created some tiled patterns. By using the Free Transfer Tool (E) and selecting the last option, you can warp the square into the proper perspective using your guides. Just pull the corners into your desired perspective and ta-da!

Rounding corners in Adobe Illustrator

Start adding those fun, little details to the kitchen to give it that classic mid-century vibe: clocks, tins, tiles, stones, rotary phone, appliances.

Step 5. Refinement

Once the illustration is starting to take shape, save a version 2. Make sure to label your layers so you don’t get lost in objects and chaos. I like to have separate layers for the items so toggling between swatches and testing out different options is easy.

Refine your shapes but also loosen up your lines. Play around with line-width and styles to get that retro feel. I like brushes that taper at an end or ones that have dashed effects. Delete any unnecessary information or clutter. At this point, you can finalize your colors and swatches.

Organizing layers in Adobe Illustrator

Step 6. Photoshop

Open a file with the same dimensions in Photoshop, set it to 330 dpi (just a bit more res than needed) and use an RGB profile for now. I usually build my working files in RGB because certain blending modes don’t have the same effect in CMYK, and we can convert to CMYK once it’s finished. Copy your vector illustration as a smart object.

Vector illustrations as Smart Objects in Adobe Photoshop

Matchbox Print Machine | Print and Registration Errors

Vigorously tested print and registration errors to add realistic print effects in Photoshop.

Move your work from Adobe Illustrator to Adobe Photoshop.

Keep a smart object of your illustration in your file. This will help with creating paths for layer masks, and selecting certain colors to apply textures.

Keep a Smart Object of Illustrator illustrations to help with paths, layer masks, color and texture.

Duplicate the art into a merged layer and flip it vertically. We will be creating a nice reflection in the shiny floor.

Duplicate image to create reflection in Photoshop.

I set the opacity to 40 and used a texture brush to fade out the reflection. I also created a layer maskfor the cream color so the reflection isn’t too busy and distracting.

Use texture brush on reflection to create organic reflection effect in Photoshop.
Final result of fading and texturing reflection in Adobe Photoshop.

Step 7. Shading and Light

Now for my favourite part! All the effort until now has been for this moment. I also start using my tablet at this stage. The pressure sensitivity gives you variation in shading and adds some dynamic visual interest.

The brushes I will be using for shading and texture are the Turbo Textures Brush Kit, specifically The Godfather of Grain, The Fuzzy Orb Generator, and The Kitchen Sink. These are my go-to brushes and they will work perfectly for adding the fun details that really give your illustration some life.

I always create my shadows and light on their own layers and use layer masks, this way you are never altering your original artwork. For my shadows, I use the colors of my illustration and set the blending mode to either multiply or linear burn, and then play around with the opacity.

Adding shading and light to your illustration in Adobe Photoshop

Turbo Textures | Subtle Shading Textures for Adobe Photoshop

Give your work textures fast with easy to use brush presets for Adobe Photoshop. Includes tool presets and brushes for easy work.

Now for highlights and shine. Lets give our objects some glow and sparkle! I create shine by using my good friend, Gaussian Blur on a shape, or by using a soft edge brush for the tiny sparkles.

Add shine to your Photoshop illustration with Gaussian Blur
Gaussian Blur panel settings in Photoshop for light effects

I then set the blending mode to Screen, Soft Light or Overlay– depending on the desired effect and the colors being used. Zoom in and double check your work often, and zoom out to check composition.

Use Screen, Soft Light, and Overlay to create subtle light effects in Photoshop

Step 8. Add Some Noise

When the illustration feels finished, I like to duplicate all layers and merge them into one top layer. Now we are going to add a subtle layer of noise. This creates a texture which gives the areas untouched by brushes a similar feel. I set the noise to 2 so it’s very subtle, but now we don’t have that vector perfection anywhere.

How to add subtle noise and texture in Photoshop

Save a web version without bleed (RBG) and a print version with bleed (CMYK).

Save a web and print version with bleed of your work in Photoshop

And there you have it! Now we are ready to head into the kitchen to make some tea!
